open frame lcd display

Full technical specifications

Panel 32" TFT LED, 1920×1080 (FHD), 16:9
Active area 698.4 × 392.9 mm
Brightness 2,500 cd/m² (with auto light sensor)
Contrast ratio 1,300:1
Viewing angles 89°/89°/89°/89° (U/D/L/R)
Response time 6 ms
Color depth 16.7M colors
Processor RK3568, 4-core @ 1.8 GHz + Mali-T764 GPU
Memory / storage 2 GB DDR3 RAM / 16 GB eMMC (expandable)
Operating system Android 9 / Android 11
Connectivity RJ45, 2× external USB, 4× internal USB, SD card, LVDS, HDMI 2.0 (4K@60Hz on custom build)
Wireless Built-in WiFi + Bluetooth; 3G/4G expandable
Network protocols LAN, WAN, WiFi, 3G/4G
Audio Built-in dual speakers; MPEG-1, AAC-LC, HE-AAC, WAV, PCM 7.1
Video formats RM/RMVB, MKV, TS, FLV, AVI, VOB, MOV, WMV
Image formats BMP, JPEG, PNG, GIF
Other formats PDF, PPT, SWF, Text, Real-time stream
Firmware update SD card; remote OTA via CMS
Power supply 100–240V AC, ≤105W
Enclosure Black panel + black bezel (custom color MOQ 20 pcs)
Dimensions (L×W×H) 721.8 × 416.3 × 72.3 mm
Net / gross weight 7.2 kg / 12.2 kg
Mounting Wall, floor stand, ceiling (portrait or landscape)
Operating temp. −10°C to +50°C
Storage temp. −20°C to +60°C
Humidity (op/storage) 5%–90% RH (non-condensing)
Panel lifespan 50,000 hours
Security Hardware dongle, login password, hierarchical user permission
